Drop-In Pad Adapters
The D2-8F two-post lift utilizes Dannmar’s drop-in lift pad adapters. Dannmar’s pads are rugged and resist hard use and gouging. Strong construction ensures safe operation. The 35 mm adapters are stackable and include a standard set to accompany each lift, helping reach the lifting points on most any vehicle.
Two-stage telescoping front and rear arms
The D2-8F features two-stage arms which are versatile enough to work with several different vehicle types. The arm sweep and minimum arm reach on this lift are extended, so the arms can lift most unibody vehicles. Typically, they will reach factory-recommended lift points and work with a wide range of wheelbases.
Low-profile, dropped-end frame contact pads
From daily drivers to race cars to high-performance import sedans, Dannmar’s car lift has the versatility to slide under your chassis without damaging your vehicle’s undercarriage or frame.
Lowered arm tube supports
Dannmar’s tube arms have been redesigned to make it easier to open doors when vehicle lift points are engaged. This is especially useful if your vehicle has low-opening doors. Dannmar makes every effort to prevent damage to your vehicle’s body with the two-post lift design.
Study In Lift DesignLift Comparisons And More
Electrical & UtilityRequirements
Concrete SpecsMinimum Floor Requirements
WarrantyCovered By 5-2-1 Warranty
Balancing SafetyFinding Center Of Balance
How To LevelLeveling A Two-Post Lift
Best Car Lift GuideIntroduction To Car Lift Types
Things To KnowBefore Buying A Car Lift
- Electric / hydraulic power system
- Large, 17″ x 19″ A36 steel base plate
- Self-lubricating dura-glide UHMW polyethylene bearings
- Safety locks in each column spaced every 3”
- Automatic arm restraints
- Heavy-duty 1/2″ aircraft-quality equalizer cables
- Oversized cable sheave diameter reduces cable fatigue
- 4-piece 35 mm stackable adapter set comes standard
- Telescoping arm design for more versatile arm positioning
- Single-point safety release
- Drop-end arms provide a lower pad height
- Dual hydraulic direct-drive cylinders
- Oversized 53″ tall carriage for superior strength
- Versatile drop-in contact pads with stackable adapters.
| Style | Floorplate |
|---|---|
| SKU# | 5175316 |
| Lifting Capacity | 8,000 lbs. (3,629 kg) |
| A – Lowered Height + Pad | 4.25” (108 mm) |
| B – Max. Lift Height (Top Lock) | 80.5” (2,045 mm) |
| C – Max. Rise | 72” (1,829 mm) |
| D – Height Overall | 123” (3,128 mm) |
| E – Width Overall | 132” (3,353 mm) or 145” (3,683 mm) |
| F – Width Outside Columns | 126.75” (3,219 mm) or 139.75” (3,550 mm) |
| G – Width Inside Columns | 105” (2,667 mm) or 118” (2,997 mm) |
| H – Drive-Thru Clearance | 93” (2,362 mm) or 106” (2,692 mm) |
| I – Floorplate Width | 8.5” (216 mm) |
| J – Floorplate Height | 1.25″ (33 mm) |
| K – Arm Reach | 32.25″ (819 mm) – 52.25” (1,327 mm) |
| Max. Load per Arm | 2,000 lbs. (907 kg) |
| Time to Full Rise | 45 seconds |
| Noise | 45 dB |
| Motor | 220 VAC / 60 Hz / 1 Ph |
| Shipping Weight | 1,733 lbs. (786 kgs) |
| Shipping Dimensions | 117″ x 25″ x 36″ (2,971 mm x 635 mm x 914 mm) |
